LOC-22TROF-DMWMCCT-EM
LOC-22TROF-DMWMCCT-EM
SKU# TR0049/TR0063
LOC-22TROF-DMWMCCT-EM - 2X2 LED TROFFER WITH 15W EMERGENCY BACKUP BATTERY, MULTI-WATTAGE, 15W 1,942LM, 19W 2,460LM, 24W 3,108LM, AND 29W 3,755LM, 129.5/W, MULTI-CCT 3500K, 4000K, AND 5000K, FROSTED, 0-10V DIMMING, AC120-277V, 110 DEGREE BEAM ANGLE
Wattage: Multiple Wattage, 15W, 19W, 24W, 29W
CCT: 3500K, 4000K, 5000K, Multiple Color Temperature
Voltage:120-277Vac
CERTIFICATIONS:
Ā Ā
_________________________________________________________________________
FEATURES AND SPECIFICATIONS.
Ā
| Warehouses, schools, factories, offices, supermarkets, logistic centers, exhibition halls and more. |
|
ā¢ Samsung 2835 LED Chips ā¢Ā Steel and Aluminum frame with matte white finish ā¢Ā Glare-free |
ELECTRICAL SPECIFICATIONSĀ
- Multi Wattage: 15W, 19W, 24W and 29W
- Default Wattage: 29W
- Multi CCT: 3,500K, 4,000K and 5,000K
- Default CCT: 5,000K
- 15W: 1,942.5LM 129.5LM/W
- 19W: 2,46035LM 129.5LM/W
- 24W: 3,108LM 129.5LM/W
- 29W: 3,755.5LM 129.5LM/WĀ
- Power Factor: 0.9
- CRI: 80
- THD: 20%
- 120-277Vac, 50/60Hz
- 0-10V dimming
- 110Ā° beam angle
- 100,000 hours lifetime | 5 year limited warrantyĀ
